Outdoor IP67 Omnidirectional Fiberglass Antenna 4G LTE 60×1000

Short Description:

Frequency: 617~960MHz; 1427-1517MHz; 1710-2700MHz
Gain: 2.5dBi @ 617-960MHz
5dBi @ 1427-1517MHz
8dBi @ 1710-2700MHz

N Connector

IP67 Waterproof

Dimension: Φ60*1000mm

Send email to us Download as PDF

Product Detail

Product Tags

Product Introduction

This 4G LTE omnidirectional fiberglass antenna is a high-performance antenna with excellent frequency range and gain. It is able to cover a variety of communication needs by supporting frequency ranges of 617-960MHz; 1427-1517MHz and 1710-2700MHz. Whether in urban or rural areas, it can provide stable and fast network connections.
The antenna radome is made of UV-resistant fiberglass fiber material, which has excellent weather resistance and UV resistance. It can maintain good performance and durability no matter in harsh environments such as high temperature, low temperature, humidity or wind and sand. This makes it a reliable choice in a variety of applications, including outdoor, industrial, and agricultural.
The antenna adopts pole mounting installation method, which is very convenient and fast. Pole size diameter ranges from 30-50MM, suitable for various pole and bracket specifications. Users only need to simply fix the antenna on the pole to install it without complicated fixing operations. This kind of installation method can save time and labor costs, and is suitable for various places and needs.

Product Specification

Electrical Characteristics
Frequency	617-960MHz	1427-1517MHz	1710-2700MHz
S.W.R.	<3.2	<3.2	<3.2
Antenna Gain	2.5dBi	5dBi	8dBi
Efficiency	≈70%	≈54%	≈69%
Polarization	Linear	Linear	Linear
Horizontal Beamwidth	360°	360°	360°
Vertical Beamwidth	70°±30°	24°±2°	20°±10°
Impedance	50 Ohm	50 Ohm	50 Ohm
Max Power	50W	50W	50W
Material & Mechanical Characteristics
Connector Type	N connector
Dimension	Φ60*1000mm
Weight	1.1Kg
Radome material	Fiberglass
Environmental
Operation Temperature	- 40 ˚C ~ + 80 ˚C
Storage Temperature	- 40 ˚C ~ + 80 ˚C
Rated Wind Velocity	36.9m/s

Antenna Passive Parameter

VSWR

Efficiency & Gain

Frequency(MHz)	610.0	620.0	630.0	640.0	650.0	660.0	670.0	680.0	690.0	700.0	710.0	720.0	730.0	740.0	750.0	760.0
Gain (dBi)	-1.57	-0.13	1.11	2.79	3.15	2.03	2.02	2.30	2.28	2.74	2.50	0.65	0.31	0.72	1.28	1.94
Efficiency (%)	40.17	49.31	54.88	64.39	63.92	73.95	86.10	94.56	91.13	93.13	83.09	74.11	71.86	68.07	67.40	72.07

Frequency(MHz)	780.0	800.0	820.0	840.0	850.0	860.0	870.0	880.0	890.0	900.0	910.0	920.0	930.0	940.0	950.0	960.0
Gain (dBi)	1.68	1.79	1.46	1.13	1.31	1.52	1.61	1.44	1.76	2.23	2.61	2.66	2.18	1.72	1.59	1.76
Efficiency (%)	75.72	77.86	67.35	63.59	69.71	67.64	66.90	67.99	69.82	74.34	76.26	75.49	70.31	67.22	63.64	61.35

Frequency(MHz)	1427.0	1437.0	1447.0	1457.0	1467.0	1477.0	1487.0	1497.0	1507.0	1517.0
Gain (dBi)	4.44	4.73	4.84	4.48	4.26	3.93	3.85	3.95	3.85	3.87
Efficiency (%)	62.44	63.02	59.68	52.21	49.31	47.83	49.04	50.75	50.02	51.14

Frequency(MHz)	1700.0	1750.0	1800.0	1850.0	1900.0	1950.0	2000.0	2050.0	2100.0	2150.0	2200.0
Gain (dBi)	4.99	5.89	5.78	5.33	5.55	5.95	5.72	6.12	5.63	6.45	6.71
Efficiency (%)	68.18	72.33	70.17	64.21	68.99	68.55	66.65	69.46	67.34	65.00	64.10

Frequency(MHz)	2250.0	2300.0	2350.0	2400.0	2450.0	2500.0	2550.0	2600.0	2650.0	2700.0
Gain (dBi)	7.62	8.13	8.01	7.63	7.78	7.97	7.90	8.09	8.35	8.34
Efficiency (%)	71.29	75.53	71.47	67.92	69.52	67.32	63.37	66.22	72.11	71.09
